Rotary Feeders

Schutte Motion Rotary Feeders are designed to provide a steady, consistent supply of material across the full inlet of a hammer mill. This helps to achieve the hammer mill’s full grinding capabilities. These rotary feeders require a VFD to allow for adjustments of the feed rate to the hammer mill. The Feeder is designed to out last competitor feeders and reduce customer down time. The rotary feeder has sloped air inlets that allow air to flow directly into the hammer mill.

The housing is made from ¼” steel, and the inside that connects with the product is made of ⅜” steel. The ⅜” travels along the full circumference of the rotor, making all product contact areas last 2-3 times longer.

The Feeder comes with a built-in magnet protection system. This system comes in two options: a manual clamp unit, or an auto self-clean unit. The built-in magnet protection system allows us to build the feeder to directly replace any other feeder on the market.

Our feeder comes with Dodge bearings and Sumitomo gear drives. We can offer TEFC or TEXP motors.

KEY FEATURES:
• Heavy Duty Magnet Protection
• Sloped Air Inlets (to prevent product build up)
• ⅜” Thick Steel Product Contact Surface
• Auto Magnet Cleaning

OPTIONAL FEATURES:
• VFD
• Micro Switch to Indicate Magnet Open
• Heavy Duty Magnet
• High Intensity Magnet
• Rare Earth Magnet
• Explosion Proof Motor
• Welded Steel Pocket Rotor

We also offer low profile/custom options available for special applications.

To find out more about our other types of conveyor systems, click here

Contact Us

Feeder with 10″ diameter rotor

Model:			2 Row	3 Row	4 Row	5 Row	6 Row	7 Row	8 Row	9 Row	10 Row	11 Row	12 Row	14 Row
Width:			9″	12″	15″	20″	24″	30″	36″	36″	40″	40″	48″	60″
	Bulk Density	shaft RPM
Soybean hulls	25	10min ________ 25max	3,450 ________ 8,625	5,175 ________ 12,938	6,885 ________ 17,213	8,610 ________ 21,525	10,335 ________ 25,838	12,060 ________ 30,150	13,785 ________ 34,463	15,510 ________ 38,775	17,220 ________ 43,050	18,945 ________ 47,363	20,670 ________ 51,675	24,120 ________ 60,300
Feed Ration, Post Mix	35	10min ________ 25max	4,830 ________ 12,075	7,245 ________ 18,113	9,639 ________ 24,098	12,054 ________ 30,135	14,469 ________ 36,173	16,884 ________ 42,248	19,299 ________ 48,248	21,714 ________ 54,285	24,108 ________ 60,270	26,523 ________ 66,308	28,938 ________ 72,345	33,768 ________ 84,420
Wood Pellets	40	10min ________ 25max	5,520 ________ 13,800	8,280 ________ 20,700	11,016 ________ 27,540	13,776 ________ 34,440	16,536 ________ 41,340	19,296 ________ 48,240	22,056 ________ 55,140	24,816 ________ 62,040	27,552 ________ 68,880	30,312 ________ 75,780	33,072 ________ 82,680	38,592 ________ 96,480
Corn	45	10min ________ 25max	6,210 ________ 15,525	9,315 ________ 23,288	12,393 ________ 30,983	15,498 ________ 38,745	18,603 ________ 46,508	21,708 ________ 54,270	24,813 ________ 62,033	27,918 ________ 69,795	30,996 ________ 77,490	34,101 ________ 85,253	37,206 ________ 93,015	43,416 ________ 108,540
Wheat	50	10min ________ 25max	6,900 ________ 17,250	10,350 ________ 25,875	13,770 ________ 34,425	17,220 ________ 43,050	20,670 ________ 51,675	24,120 ________ 60,300	27,570 ________ 68,925	31,020 ________ 77,550	34,440 ________ 86,100	37,890 ________ 94,725	41,340 ________ 103,350	48,240 ________ 120,600

Feeder with 14″ diameter rotor

Model:			2 Row	3 Row	4 Row	5 Row	6 Row	7 Row	8 Row	9 Row	10 Row	11 Row	12 Row	14 Row
Width:			9″	12″	15″	20″	24″	30″	36″	36″	40″	40″	48″	60″
	Bulk Density	shaft RPM
Soybean hulls	25	10min ________ 25max	5,610 ________ 14,025	8,520 ________ 21,300	11,535 ________ 28,838	14,445 ________ 36,113	17,460 ________ 43,650	20,265 ________ 50,663	23,715 ________ 59,288	26,205 ________ 65,513	29,430 ________ 73,575	32,025 ________ 80,063	35,580 ________ 88,950	40,545 ________ 101,363
Feed Ration, Post Mix	35	10min ________ 25max	7,854 ________ 19,635	11,928 ________ 29,820	16,149 ________ 40,373	20,223 ________ 50,558	24,444 ________ 61,110	28,371 ________ 70,928	33,201 ________ 83,003	36,687 ________ 91,718	41,202 ________ 103,005	44,835 ________ 112,008	49,812 ________ 124,530	56,763 ________ 141,908
Wood Pellets	40	10min ________ 25max	8,976 ________ 22,440	13,632 ________ 34,080	18,456 ________ 46,140	23,112 ________ 57,780	27,936 ________ 69,840	32,424 ________ 81,060	37,944 ________ 94,860	41,928 ________ 104,820	47,088 ________ 117,720	51,240 ________ 128,100	56,928 ________ 142,320	64,872 ________ 162,180
Corn	45	10min ________ 25max	10,098 ________ 25,245	15,336 ________ 38,340	20,763 ________ 51,908	26,001 ________ 65,003	31,428 ________ 78,570	36,447 ________ 91,193	42,687 ________ 106,718	47,169 ________ 117,923	52,974 ________ 132,435	57,645 ________ 144,113	64,044 ________ 160,110	72,981 ________ 182,453
Wheat	50	10min ________ 25max	11,220 ________ 28,050	17,040 ________ 42,600	23,070 ________ 57,675	28,890 ________ 72,225	34,920 ________ 87,300	40,530 ________ 101,325	47,430 ________ 118,575	52,410 ________ 131,025	58,860 ________ 147,150	64,050 ________ 160,125	71,160 ________ 177,900	81,090 ________ 202,725
